B2 Audio REFERENCE 3" 6-Ohm 50 Watt RMS Bamboo Infused Midrange Speaker REF3MR

1 469,3 DKK / Par
B2-REF3MR B2

Liknande produkter

DD Audio AM-3
DD Audio AM-3
2 093 DKK 1 561,42 DKK / Par
-25%
Excursion PX 3M
Excursion PX 3M
1 469,3 DKK / Par
Rebec CS80
Rebec CS80
1 816,5 DKK / Par
Rebec RL70
Rebec RL70
2 026,5 DKK / Styck

Midrange Specifications:

  • RMS Power Handling: 50W
  • Nominal Impedance: 6 Ohm
  • Voice Coil Diameter: 1"
  • Frequency Response: 50 Hz ~ 25 KHz

Thiele & Small Parameters:

  • Free Air Resonance (Fs): 159 Hz
  • Resistance (Re):5.2 ohm
  • Mechanical Factor (Qms): 5.54
  • Electrical Factor (Qes): 1.43
  • Total Factor (Qts): 1.14
  • Equivalent Volume (Vas): 0.5 L
  • L Efficiency: 0.142%
  • Compliance (Cms): 354 um/N
  • BL Factor (BL): 3.2 TM
  • Moving Mass (Mms): 2.8 g
  • Sound Pressure Level (SPL): 83.6 dB

Measurements:

  • Overall Diameter: 3.59" / 91.4mm
  • Mounting Diameter: 3.03" / 77mm
  • Front Mount Baffle Cutout: 3.15" / 80mm
  • Overall Depth: 1.91" / 48.6mm
  • Mounting Depth: 1.53" / 38.9mm
  • Sold as: (Pair)
